ATK-008E | 8m Luxury Intelligent Electric Spray Booth: The Precise, Efficient, and Reliable Professional Painting Solution

The ATK-008E is a premium spray booth designed for professional clients who demand ultimate painting quality and operational efficiency. Integrating intelligent electric heating, powerful ventilation/purification, and a robust structure, it is the ideal choice for high-standard automotive body shops, commercial vehicle maintenance, and precision industrial coating applications.

Core Advantages & Technical Highlights:

• Intelligent & Efficient Heating System:

  • Equipped with 10 sets of halogen infrared baking lamps totaling 30KW, providing strong heat penetration and uniform curing.

  • Features an intelligent temperature controller, rapidly heating the booth to 40°C within 5-8 minutes, with a maximum baking temperature of 80°C, significantly reducing cycle times and enhancing paint finish hardness and quality.

• Powerful Ventilation & 3-Stage Purification:

  • The ventilation system comprises 2×5.5KW high-capacity double-intake centrifugal fans (supply) and 1×7.5KW centrifugal exhaust fan, enabling tens of thousands of cubic meters of air exchange per hour to swiftly remove overspray and VOCs.

  • A three-stage filtration system includes primary (>10μm), ceiling (>4μm, efficiency >98%), and floor (multi-layer fiberglass) filters, ensuring an almost dust-free environment for flawless paint finishes.

• Robust Industrial Construction:

  • Walls are constructed with high-quality double-layer color steel composite panels filled with high-density (100KG/m³) fire-resistant rock wool, offering excellent insulation and flame retardancy.

  • The basement is a reinforced platform made of galvanized steel sheets and square tubes, fitted with anti-rust steel grilles and thickened walking floors (5mm) for overall stability.

  • The modular galvanized steel fan cabinet (1.1*2.2m) offers flexible placement on the left, right, or back to suit workshop layouts.

• User-Friendly Intelligent Control & Safety:

  • Integrated intelligent control panel allows one-touch switching between “Spray”, “Bake”, and “Heat” modes, with programmable temperature and timer functions.

  • Includes an emergency stop button, comprehensive LED lighting (24 ceiling lights + 8 side wall lights), and observation doors with high-temperature glass for intuitive and safe operation.

Standard Specifications Overview:

• Model: ATK-008E

• External/Internal Dimensions: 7720×4600×3500mm / 7620×4500×2800mm

• Heating Type: Electric Heating (220V/380V, 50Hz)

• Total Power: 38 KW

• Packaging: Approx. 19 CBM, 3500kg, recommended shipment in a 20GP container.

Ideal For:
High-end automotive 4S shop paint centers, large comprehensive repair facilities, bus/truck fleet maintenance stations, aerospace component coating, and precision equipment housing painting—applications where environmental cleanliness and process control are paramount.

We can provide customized installation layout and electrical configuration advice based on your specific workshop conditions and process requirements. Please contact our technical team for a detailed proposal and quotation.
