The ATK-006B is a cost-effective 6m standard spray booth focused on delivering a clean, stable painting environment. While omitting heating, it retains powerful ventilation (30,000 m³/h) and a three-stage filtration system, making it a reliable choice for auto quick-service shops and body shops in temperate climates or with budget considerations.
| Minimum Order Quantity : | 1pcs | Price : | To be negotiated |
| Packaging Details : | 40GPor20GP/unit | Delivery Time : | 15days To be negotiated |
| Payment Terms : | L/C, T/T | Supply Ability : | 50 Unit/Units per Month Industrial Spray Booth bus spray booth |
| Place of Origin: | Jiangsu, China | Brand Name: | Autoke |
| Certification: | CE | Model Number: | ATK-006B |
ATK-006B | 6m Economical Standard Spray Booth: Focused on Core Functionality, Delivering High Value
The ATK-006B is a cost-effective spray booth designed for start-up auto repair shops, small body shops, training institutions, and users with minimal baking requirements. By omitting the heating module, it concentrates investment on the core essentials—ventilation, filtration, and build quality—offering a professional, clean, and safe painting workspace at a highly competitive initial cost.
Core Positioning & Advantages:
Optimized for Cost:
Eliminates heating to significantly reduce both purchase price and ongoing energy costs, ideal for budget-conscious users entering the market.
Suitable for environments with moderate temperatures, where air-dry or fast-dry paints are used, or where forced curing is not required.
Professional Ventilation & Cleanliness:
Full-Power Ventilation: Retains the 2×4KW double-intake centrifugal fans (30,000 m³/h total supply) and 1×5.5KW exhaust fan (19,000 m³/h) to swiftly remove overspray and VOCs, ensuring operator safety and air quality.
Complete Filtration: Features the full three-stage filtration system (primary >10μm, ceiling >4μm @ >98% efficiency, floor multi-layer fiberglass), guaranteeing clean air supply for quality finishes.
Robust & Durable Construction:
Same double-layer fire-resistant color steel rock wool panels (100KG/m³ density) as premium models, providing insulation, soundproofing, and fire resistance.
Reinforced basement made of galvanized steel sheets and square tubes, with 4 auxiliary legs for over 5-ton load capacity.
Modular galvanized steel fan cabinet (1.1*2.2m) offers flexible placement (left/right/back).
Complete Basic Features:
Professional Lighting: 24x 18W LED ceiling lights (45° angle) and 8x 48W side wall LED lights for uniform, shadow-free illumination.
Intelligent Control: Standard integrated control panel with lighting, spray mode, fan control, and emergency stop functions.
Specifications Overview:
Model: ATK-006B
External/Internal Dimensions: 6000×4000×3500mm / 5900×3900×2800mm
Heating: None
Ventilation Power: Supply 2×4KW + Exhaust 1×5.5KW
Total Electrical Power: For ventilation, lighting, and controls only (much lower than heating models).
Packaging: ~19 CBM, fits standard containers (3 units in a 40HQ).
Ideal For:
New auto quick-service shops, small body and paint workshops.
Vocational schools and training centers for automotive repair.
Fleet maintenance points for local repairs and painting.
Regions with consistently warm climates where additional heating is unnecessary (e.g., parts of Southeast Asia, Middle East, Africa).
As an additional spray station in existing workshops for non-bake painting tasks.
Future Upgrade Path:
The ATK-006B is designed with flexibility. Standard electrical and structural interfaces allow for easy future retrofitting with electric or diesel/gas heating modules, protecting your initial investment as your business grows.
The ATK-006B demonstrates that a professional painting environment can be affordable. We are committed to providing optimal solutions for every stage and budget. Contact our technical consultants for a free assessment of whether this model fits your process or to discuss future upgrade options.
