ATK-7000-DH-PRO+ 7m Luxury Diesel-Heated Spray Booth (Enhanced Ventilation Version)

Building upon the standard luxury model, this product features a professional upgrade to its core ventilation system, designed to provide a more powerful and stable air environment for high-frequency, high-quality painting operations. Tailored for large vehicle repair centers, professional body shops, and high-standard industrial coating lines, it is the professional choice that balances efficient production with outstanding finish quality.

Core Upgrades & Advantages:

🚀 Upgraded High-Power Ventilation System

• Air Supply System: Utilizes 2×5.5KW high-power double-intake centrifugal fans, providing a total air supply of up to 30,000 m³/h for stronger airflow and faster air exchange.

• Exhaust System: Equipped with a 1×7.5KW high-efficiency centrifugal exhaust fan (19,000 m³/h), ensuring rapid removal of paint mist and volatiles to maintain a clean, positive-pressure environment.

• Value: The enhanced airflow effectively reduces paint mist settling time, improves work pace, and provides better environmental safety margins for large workpieces or high-concentration spraying.

🔥 High-Efficiency Diesel Heating System

• Features the industry-renowned RIELLO G20 diesel burner for stable and reliable performance.

• Rapid heat-up to 40°C within 5-8 minutes, with a maximum baking temperature of 80°C. Meets various process needs from standard painting to high-temperature curing, offering fast heating and economical operation.

🛡️ Triple-Stage Precision Air Filtration

• Primary Filter: Captures particles >10μm with >90% efficiency.

• High-Efficiency Ceiling Filter (White): Filters particles >4μm with >98% efficiency, ensuring clean incoming air.

• Multi-Layer Fiberglass Floor Filter (Blue): >90% filtration efficiency, effectively collecting overspray and purifying exhaust air.

• Together, they create a clean painting space, forming the foundation for high-quality finishes.

🏗️ Robust Industrial Construction

• Walls: Double-layer color steel fire-resistant insulated panels with high-density (100kg/m³) rock wool core for thermal insulation, soundproofing, and flame retardancy.

• Roof: Galvanized steel sheet, corrosion-resistant.

• Floor: 300mm high raised platform made of galvanized steel sheets, with anti-rust galvanized steel grilles and walkways. Overall load capacity ≥5 tons, ensuring durability.

⚙️ Intelligent Integrated Control System

• Unified control panel integrating lighting, painting, baking, timer, temperature control, and emergency stop functions.

• Intuitive operation enables standardized process management and precise control, enhancing safety and work efficiency.

Main Technical Specifications

• External Dimensions: 7000 × 4000 × 3350 mm

• Internal Dimensions: 6900 × 3900 × 2650 mm

• Heating Method: Diesel (RIELLO G20)

• Total Power: Approx. 15 KW (Diesel Heating Version)

• Voltage/Frequency: 220V / 380V, 50Hz

• Packing: Approx. 19 CBM/set, Weight ~3500 kg

Ideal Applications

• Professional repair and painting centers for large buses, trucks, and construction machinery.

• High-end automotive 4S shop body & paint centers and large comprehensive repair facilities.

• Industrial manufacturers with stringent requirements for painting environment airflow and cleanliness.

• Upgrade and retrofit projects aiming to improve existing production line efficiency and quality.

We offer color customization and flexible adjustments to certain configurations to meet your specific site and process requirements.

Contact our technical consultants for detailed technical documentation, tailored configuration proposals, and a personalized quotation.
