The Autoke 7m Electric Heated Spray Booth (Model: ATK-LS7-032E) delivers professional-grade painting performance with 30KW halogen infrared heating, a powerful ventilation system (2×4KW intake + 5.5KW exhaust, 25,000 m³/h airflow), and enhanced safety flooring. Featuring a spacious interior (6900×3900×2800mm), robust 5cm rock wool panels, three rows of non-slip metal grill floors, bright LED lighting, and multi-stage filtration, this booth ensures fast curing, superior finish quality, and operator safety. Factory direct – customizable for your specific requirements.
| Minimum Order Quantity : | 1pcs | Price : | To be negotiated |
| Packaging Details : | 40GPor20GP/unit | Delivery Time : | 15days To be negotiated |
| Payment Terms : | L/C, T/T | Supply Ability : | 50 Unit/Units per Month Industrial Spray Booth bus spray booth |
| Place of Origin: | Jiangsu, China | Brand Name: | Autoke |
| Certification: | CE | Model Number: |
ATK-LS7-032E |
The Autoke 7m Luxury Spray Booth with Electric Heating combines rugged construction, efficient ventilation, and powerful electric heating to deliver consistent painting and drying results. Equipped with 30KW halogen infrared lamps and a high-performance ventilation system, this booth is ideal for workshops requiring fast turnaround and professional-grade finishes. The spacious interior (6900×3900×2800mm) accommodates cars, vans, and light trucks, while the advanced control system, non-slip flooring, and comprehensive filtration ensure a clean, safe working environment.
Durable Construction
Wall panels: 5cm thick high-density rock wool (100 kg/m³) with 0.4mm steel covers – fire-resistant, soundproof, and thermally insulated.
Galvanized steel roof panels, anti-flame treated.
Heavy-duty basement with plate-type convex platform, made of galvanized steel sheet and square tubes, height 300mm.
Enhanced flooring system:
Two rows of flat steel grilles (galvanized, 30×4mm) for optimal airflow.
Three rows of metal non-slip grill floors (widths: 53cm, 90cm, 53cm) for safe operator access even in wet or oily conditions.
Two rows of walking floors (90cm each side) for easy movement.
Four auxiliary legs provide additional support, capacity up to 5 tons.
Powerful Ventilation System
Intake: 2×4KW YDW double-intake centrifugal fans, total airflow 25,000 m³/h for optimal air distribution.
Exhaust: 1×5.5KW YDW centrifugal fan ensuring efficient removal of overspray and fumes.
Luxury fan box made of 1mm galvanized sheet with square tube frame, spray-coated for durability.
Cabinet dimensions: 1.1×2.2m, can be installed on left, right, or rear side of booth.
Includes 90° elbow duct.
Efficient Electric Heating
Heating elements: 10 sets of halogen infrared lamps, total 30KW (3×1KW per set).
Heating time: 5–8 minutes to reach 40°C; maximum baking temperature 80°C.
Ideal for fast curing of paints and coatings with clean, silent operation and no emissions.
Total power: 38KW (electric version).
Spacious Access
Main gate: Four-piece metal front doors with tempered glass windows, equipped with handle and lock, 5mm high-temperature resistant glass.
Side safety door for emergency exit and convenient access.
Superior Illumination
Ceiling: 24×18W LED lights (8 groups of 3) angled at 45° for uniform overhead lighting.
Side walls: 8×48W LED lights eliminate shadows and improve visibility during detailed work.
Multi-Stage Filtration System
Primary filter: Captures particles >10μm, efficiency >90%.
Ceiling filter (white): Captures particles >4μm, efficiency >98%.
Floor filter (blue): Multi-layer fiberglass filter, efficiency >90%.
Ensures a clean painting environment and high-quality finish.
Roof System
Beam made of galvanized square pipes, connected with angle iron and screws for structural integrity.
Plenum made of galvanized steel, powder-coated for durability.
Intelligent Control System
User-friendly panel with switches for lighting, painting, baking modes, temperature control, timer, and emergency stop.
Real-time monitoring and adjustment for optimal operation.
Electrical & Performance
Voltage: 220V/380V, 50Hz.
Professional-grade components designed for continuous commercial use.
| Parameter | Details |
|---|---|
| Model | ATK-LS7-032E |
| Outer Size (L×W×H) | 7000×5200×3200 mm |
| Inner Size (L×W×H) | 6900×3900×2800 mm |
| Package Size | 4.2×2.2×2.1 m (19 CBM) |
| Weight | Approx. 3500 kg |
| Wall Panel | Rock wool, 50mm thick, density 100kg/m³, steel thickness 0.4mm |
| Floor Grilles | 2 rows flat steel grilles (30×4mm) + 3 rows non-slip grill floors |
| Walking Floors | 2 rows, 90cm each side |
| Ventilation | 2×4KW intake fans (25,000 m³/h) + 1×5.5KW exhaust fan |
| Heating | 30KW halogen infrared lamps (10 sets), max 80°C |
| Lighting | Ceiling: 24×18W LED; Side walls: 8×48W LED |
| Doors | Main: 4-leaf metal with tempered glass; Side safety door |
| Fan Box | Luxury construction, 1mm galvanized sheet with square tube frame |
| Filtration | Primary, ceiling, floor filters (pre-installed) |
| Control System | Intelligent panel with timer, temp control, emergency stop |
| Voltage/Frequency | 220V/380V, 50Hz |
| Total Power | 38 KW (electric version) |
| Color Options | Red, Blue, White, Gray, Orange, etc. |
| Warranty | 12 months from B/L date |
| Delivery Time | 30 days after payment (EXW) |
| Shipping | 1 set per 20GP container; 3 sets per 40HQ container |
✅ Factory Direct Supply – Competitive pricing without middlemen
✅ OEM Customized Solutions – Tailor size, color, and accessories to your needs
✅ One-Stop Solution – From structure to heating and ventilation
✅ Industrial Equipment Manufacturer – Proven quality and reliability
✅ Designed for Commercial Use – Heavy-duty components for continuous operation
✅ Enhanced Floor Safety – Non-slip grill floors for operator confidence
✅ Clean & Silent Operation – Electric heating with no emissions, ideal for indoor use
✅ Global Shipping – Easy container loading and worldwide delivery
Automotive body shops and collision repair centers
Car and van painting
Industrial coating and finishing lines
Custom paint and restoration workshops
Facilities requiring emission-free heating solutions
