AUTOKE Industrial Paint Booth Introduce

AUTOKE industrial paint booth is a controlled enclosure designed for professional spraying, coating, and finishing applications. It provides a clean, well-ventilated, and temperature-controlled environment to ensure consistent paint quality, higher efficiency, and compliance with environmental and safety standards.


We also offer paint booths specifically designed for water-based paints.
Customized spray booths in any size and any color are available.

Our spray booths are exported to 50+ countries, including the United States, the United Kingdom, France, and the United Arab Emirate

Types of Industrial Spray Booths

automotive paint booths usually include

  • Industrial spray booths
  • Down-draft paint booths
  • Cross-draft paint booths
  • Side-draft paint booths
  • Dry filter paint booths
  • Wet paint booths
  • Open-face spray booths
  • Fully customized
  • industrial paint booth systems

Each type can be selected based on product size, coating material, airflow requirement, and production volume.



Industrial Paint booth product list

Structure and Configuration

  • Intake and exhaust
  • filtration systems
  • High-efficiency lighting
  • Ventilation fans and ducting
  • Optional heating and curing units
  • Modular designs allow for future expansion or upgrades.

Application Scenarios

  • Manufacturing and fabrication plants
  • Automotive and commercial vehicle finishing
  • Heavy equipment and machinery coating
  • Metal furniture and component finishing
  • Industrial maintenance and refurbishment

What structures does the AUTOKE paint booth consist of?

  • Wall panel

  • Galvanized steel roof panel, anti-flame

  • The wall panel is made of high-density rock wool with a bulk density of 100KG/m3

  • High quality double construction insulation EPS colorful steel skin panel. Fire resistant wall 50-75mm, two layers δ0.462mm steel coverwith fire resistant thermal insulation materials in.

wall panel

  • Door

  • Four pieces metal structure front doors with tempered glass

  • Aluminum plastic frame glass door/sheetmetal door

  • Fan Box

  • The air box is made of 1mm galvanized sheet metal, filled with square tube frame inside, treated with spray coating on the outside, integrated casting, sturdy and durable

Car Spray Booth

  • Heating Systerm

  • Electric heating: Infrared or graphene heating baking lamps
  • Diesel heating or gas heating: RIELLO heater, compliant with European CE standards, takes 5-8 minutes to heat up to 40 ℃, maximum baking temperature is 80 ℃

  • floor

  • Plate type pressing convex platform, made by high quality galvanized steel sheet and square tubes assembling

  • Equip flat steel grilles (Galvanized) made by flat bar and round steel，Spray treatment， rust preventio

  • Rows walking floors(Galvanized) Spray treatment, rust prevention

  • Add 4 auxiliary legs to improve support，can support at least 5t

Automotive Paint Booth
9m Car Paint Booth
9m Car Paint Booth

  • Filter system

  • Primary filtration, top filtration, bottom filtration or side wall filtration

  • Ceiling filter Technical data

    Filter level: F5/M5 (EN779), EU5 (EUROVENT)

    Filter object: >1μm particles

    Flame retardant grade: F1 (DIN 53438), B1 (GB/T17591-2006)

    Average weight efficiency: ≥98% (ASHRAE52.1-1992)

  • Floor filter (Blue)

    Paint stop Technical data

    Filter level :G3 (EN779), EU3 (UROVENT)

    Filter object: Paint mist, oil mist, dust particles

    Paint mist weight efficiency: AR-50≥90%, AR-75≥95%, AR-100≥98%

How to Choose the Right Paint Booth？

  • Measure your own space to determine the appropriate size, whether for a car, a truck or furniture.
  • Heating methods: Electric heating, diesel heating, gas heating. Choose the one according to your local conditions.

Paint Booth Price & Cost Factors

  •  Size of the spray painting room, type of panel, heating method, thickness of steel plate etc.
  • The general price ranges from $6000 -$10000 for an automotive paint booth. The transportation requires a 20gp container or a 40hq container, and the cost including customs duties and freight is generally $6500 – $15000.Need to obtain the transportation cost and contact the sales team via WhatsApp or email. The specific cost depends on the country. In some countries, the goods can only be transported to the port and then cleared by themselves. The customer needs to have the clearance capability. The more you purchase, the lower the transportation cost will be. One 40hq container can hold three standard-sized paint booths. If other repair shop equipment is also needed, it can be purchased and transported together. Please check the website for details.

Paint Booth Installation Requirements

  • Requirements for site space and layout
  •  Concrete paving on the ground
  • Planning of ventilation system
  • Heating system and energy planning
  •  Installation drawings will be provided by us. Remote guidance for installation issues will be offered.

Why choose AUTOKE automotive paint booth

AUTOKE automotive paint booths are designed for professionals who demand quality, efficiency, and reliability.

  • ✅ Stable Airflow & Clean Finish
    Advanced ventilation and multi-stage filtration deliver consistent, high-quality paint results.

  • ✅ Energy-Efficient Heating System
    Fast curing with diesel, gas, or electric options—lower operating costs, higher productivity.

  • ✅ Custom Size for Cars & Trucks
    From standard car spray booths to large truck paint booths, tailored to your workshop.

  • ✅ Built to Meet Global Standards
    Designed for safety, environmental compliance, and long-term industrial use.

  • ✅ Reliable Manufacturer Support
    Professional installation guidance and after-sales service you can trust.

👉 Upgrade your workshop with an AUTOKE paint booth.Contact us now for a customized solution and quotation.
